Understanding AI-Driven Test Solutions in Semiconductor Manufacturing – FAQ

Authors: Marc Jacobs and Nika Ptushkina

AI-driven solutions are transforming the semiconductor industry, offering innovative ways to enhance manufacturing and testing operations. Below, we’ve compiled a comprehensive FAQ guide to help you better understand how AI is reshaping test engineering.

What Are AI-Driven Test Solutions?

AI-driven test solutions use advanced machine learning models and data infrastructure to optimize semiconductor testing processes. These solutions aim to reduce costs, improve quality, and increase efficiency in manufacturing.

Why Is AI Important in Semiconductor Testing?

As the semiconductor industry evolves with innovations like 3D packaging and AI integration, testing has become more complex. AI helps test engineers manage this complexity by offering predictive insights, streamlining processes, and addressing challenges like cost control and test efficiency.

What Are the Core Components of AI in Manufacturing?

To implement AI effectively in a manufacturing environment, three core components must work together:

1. Data: High-quality, relevant data is the foundation. This includes wafer sort and final test results, WAT results, and optionally, wafer fab history, and process control data.
2. Infrastructure: A robust data infrastructure moves production datasets to the right place for model training and execution.
3. Models: Machine learning models analyze data and generate actionable, predictive insights.

How Are AI Models Trained for Semiconductor Testing?

AI models are created through a structured pipeline:

1. Data Retrieval: Accesses a database containing all relevant test and manufacturing data, such as test results and wafer fab history
2. Parameter Screening: Reduces a large number of data parameters to a smaller, meaningful set.
3. Model Building: Uses AI clusters for scalable and efficient computation to create predictive models.
4. Model Deployment: Deploys the models on the factory floor for specific use cases.

What Is a Data Feed-Forward Infrastructure?

Data feed-forward infrastructure ensures the right data gets to the right place at the right time. The process includes:

1. Capture and Transport: Collecting data at the source and sending it to a central database.
2. Data Recall and Preparation: Retrieving only the necessary data points for a model to avoid system overload.
3. Secure Data Transfer: Transferring processed data securely to factories, across different locations and suppliers.
4. Edge Integration: Integrating data directly with testers on the factory floor to enable real-time decision-making.

How Does Data Feed Forward (DFF) Enable AI-Driven Testing? ?

The integration of Data Feed Forward (DFF) methodologies with AI-driven test solutions represents a significant advancement in semiconductor testing. DFF enables the capture and utilization of critical data from upstream testing processes to dynamically determine and streamline downstream test execution. This approach ensures that the most relevant and necessary tests are performed, potentially leading to optimized test time on a unit-by-unit basis.?

By leveraging DFF infrastructure, test programs can adapt dynamically, using insights from upstream tests—such as wafer sort results or early functional tests—to expedite or improve later stages like final test.

Advanced AI models, integrated with a robust DFF framework, make it possible to extract actionable insights from this data flow in real time, enabling more reliable and optimized semiconductor manufacturing workflows.

See section below for in-depth key AI-driven, DFF enabled, test solutions.

What Are the Key AI-Driven Test Solutions?

AI can be applied to solve specific challenges in semiconductor testing. Here are four key solutions:

1. Predictive Test

• What it does: Predicts which tests can be skipped without compromising quality.
• How it works: Uses wafer sort data to forecast final test outcomes. Units predicted to pass can skip specific test suites.
• Impact: Reduces test time and costs while maintaining product quality.

2. Predictive Burn-In

• What it does: Identifies units that can bypass the expensive burn-in process without reliability issues.
• How it works: Analyzes early-stage test data to predict units that meet reliability targets without burn-in.
• Impact: Saves costs, increases capacity, and reduces the need for expensive hardware.

3. Predictive Binning

• What it does: Detects failures earlier in the process.
• How it works: Uses wafer sort data to predict final test failures, allowing defective parts to be scrapped early.
• Impact: Saves assembly and test costs by avoiding unnecessary processing of defective units.

4. Analog Trim

• What it does: Improves the precision and accuracy of analog IP blocks.
• How it works: Feeds multi-temperature data into models to optimize the trim process. Predicts expected results to avoid mis-trim.
• Impact: Improves analog IP performance, prevents scrap, and enhances yield.

What Are the Benefits of AI in Test Engineering?

AI-driven test solutions offer measurable improvements, including:

• Reduced costs through optimized test flows and skipping unnecessary processes.
• Improved quality by catching defects early and enhancing precision and accuracy.
• Increased efficiency by automating decisions and reducing manual intervention.

How Can I Get Started with AI-Driven Test Solutions?

To integrate AI-driven test solutions into your processes, you’ll need:

1. High-quality data and a robust data infrastructure.
2. Scalable machine learning models for predictive insights.
3. A strategic approach to deploying these models on the factory floor.

Want to Learn More?

Discover how AI can transform your semiconductor testing processes. With solutions like predictive test, predictive burn-in, and analog trim, you can reduce costs, improve quality, and unlock new efficiencies.

Sign up for a demo today to see how AI can make a difference for your business!
